16pin OBDII Passthru Cable with Power Break Out and IP68 Rating for Heavy-Duty Automotive Wiring Harness
Détails sur le produit:
| Lieu d'origine: | Guangdong, Chine |
| Nom de marque: | Edgarcn & EdgarWireHarness |
| Certification: | IATF16949 TS16949 UL |
| Numéro de modèle: | J1939 & J1962 |
Conditions de paiement et expédition:
| Quantité de commande min: | 10000 |
|---|---|
| Prix: | $1.40-1.50 |
|
Détail Infomation |
|||
| Type de connecteur: | Deutsch J1939 HD-16-9-1939S-P080 HD-10-9-1939P-P080 | Comptage des broches: | 2 broches |
|---|---|---|---|
| Type de fil: | UL 1007 18 # et 16 # | Conservation des contacts: | 20 livres |
| Traction de la traction: | > 20 lbs (18 #),> 25 lbs (16 #) | Température de fonctionnement: | -40 ℃ à + 125 ℃ |
| Résistance aux vibrations: | 20 g à 10-2000Hz pendant 2 heures | Note IP: | IP68 |
| Profondeur imperméable: | 1,2 mètre pendant 24 heures | Type de terminal: | 1060-16-0122 |
| Modèle d'échec: | Dommage de fil, grommet cassé | Matériel: | Scellé en caoutchouc en silicone, thermoplastique |
| Série de connecteurs: | EDG-HD | Options de couleur: | ROUGE, NOIR, BLEU, VERT |
| Longueur de coutume: | Oui | ||
| Mettre en évidence: | 16pin OBDII Passthru Cable,IP68 Rating Automotive Wiring Harness,Power Break Out Diagnostic Connector Cable |
||
Description de produit
The EDG-HD series is an environmentally sealed silicone rubber thermoplastic cylindrical connector designed for fast, easy, trouble-free assembly in heavy-duty diagnostic applications including trucks, buses, cross-country vehicles, cranes, and forklifts. When mated, the contacts are protected from water, dust, oils, fuel, road salt, grease, mud, and other contaminants.
- Operating temperature range: -40℃ to +125℃ (no cracking, chipping, or leaking after 20 test cycles)
- Withstands 20 G's sinusoidal vibration at 10-2000Hz for 2 hours in three mutually perpendicular planes with no mechanical damage
- IP68 rated - waterproof with immersion under 1.2 meters of water for 24 hours
| Terminal Type | Wire Type | Contact Retention | Ref Crimp Tensile | Failure Model |
|---|---|---|---|---|
| 1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
| 1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS | Grommet broken |
| Terminal Type | Wire Type | Contact Retention | Ref Crimp Tensile | Failure Model |
|---|---|---|---|---|
| 1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
| 1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS | Grommet broken |
Packaging can be customized to client specifications. Standard lead times:
| Quantity (PCS) | 1 - 1000 | 1001 - 5000 | >5000 | Mold/Tooling |
|---|---|---|---|---|
| Est. Time (Days) | 20 | 25 | To be negotiated | 30 days more |
International shipping available via DHL, UPS, FedEx, TNT, ARAMEX, and EMS. Options for air, sea, or other shipping methods.
